Product name:

PE Battery Separator

Inquire Now None

PE Separator that we are offering is manufactured by making use of anti-aging Polyethylene or polythene material with the glass fibre mat pasted on. This kind of separator features in the finest machinery tensile strength and great resistance of super vibration, which helps to avoid the active materials on the plate from falling off. Therefore, the life of the batteries will be extend. Such product is ideal to be applied to any motive lead-acid or high vibration batteries like tractor or taxi. In addition to this, the PE+GM Separator is also suitable for batteries fitted in the machinery of construction.

PE+GM Separator would enhance the separator's oxidation resistance by separate the separator with the plate. The flat glass mat also will prevent the plate active material from shedding, and extend battery's life. Adapt to high vibration and deep discharge batteries, such as batteries for engineering machinery, taxi and tractor.

Item	Unit	Parameters
		PE+GM 0.300	PE+GM 0.600	PE+GM 0.800
O/A	mm	Standard±0.100	Standard±0.100	Standard±0.100
Laminate Inset from Separator Edg	mm	8.0±2.0	8.0±2.0	8.0±2.0
Electrical Resistance	Ω.d㎡	≤0.0015	≤0.0015	≤0.0015
Porosity	％	≥55	≥55	≥55
Moisture Content	％	≤4.0	≤4.0	≤4.0
Dimension Stability	％	≤1.0	≤1.0	≤1.0
Acid Weight Loss	％	≤4.0	≤4.0	≤4.0
Fe Content	％	≤0.010	≤0.010	≤0.010
Cl Content	％	≤0.030	≤0.030	≤0.030
Reducing Substance	Ml/g	≤10	≤10	≤10
